| General |
| size |
139.7 x 42.2 x 33.5 mm (length x width x height) |
| weight |
179 g |
| Number of microphones |
3 |
| Touch screen |
Size: 2.0 inches Resolution: 314 x 556
Brightness: 700 nits |
| Compatible SD cards |
microSD (up to 512GB) |
| Recommended microSD cards |
Recommended models:
SanDisk Extreme Pro 32GB V30 A2 UHS-I Speed Class 3
Kingston Canvas Go!Plus 64GB UHS-I Speed Class 3
Kingston Canvas Go!Plus 128GB UHS-I Speed Class 3
Kingston Canvas React Plus 64GB UHS-II Speed Class 3
Kingston Canvas React Plus 128GB UHS-II Speed Class 3
Kingston Canvas React Plus 256GB UHS-II Speed Class 3
Lexar Pro 256GB SDXC UHS-I V30 R160/W120 (1066x)
Lexar Pro 512GB SDXC UHS-I V30 R160/W120 (1066x) |
| Gimbal |
| Operational range |
Pan: -235° to 58°
Tilt: -120° to 70°
Roll: -45° to +45° |
| Mechanical Range |
Pan: -240° to 63°
Tilt: -180° to 98°
Roll: -220° to 63° |
| Maximum movement speed |
180.0°/s |
| Angle vibration range |
±0.005° |
| camera |
| sensor |
1-inch CMOS sensor |
| lens |
Focal length: 20 mm (35mm format equivalent)
Aperture: f/2.0
Focus range: 0.2 m to ∞ |
| ISO sensitivity |
Photos: 50-6400
Video: 50-6400
Low light video: 50-16000 |
| Electronic Shutter Speed |
Photo: 1/8000 sec. to 1 sec. Video: 1/8000 sec. to 1/X sec. (X: frame rate setting value) |
| Maximum still image size |
16:9, 3840×2160
1:1, 3072×3072 |
| zoom |
Digital zoom Photo: 3840x2160, 2x Video: 1080p, 4x; 2.7K, 3x; 4K, 2x
UVC (USB Video Class) & Live Streaming: 1080p, 4x Slow Motion/Time Lapse: Not available |
| Still Image Mode |
Single shot: approx. 9.4 MP
Countdown: Off/3/5/7 seconds Panorama: 180°, 3x3 |
| Regular video recording |
4K (16:9): 3840×2160@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
3K (1:1): 3072×3072@24/25/30/48/50/60fps
2160p (1:1): 2160×2160@24/25/30/48/50/60fps
1080p (1:1): 1080×1080@24/25/30/48/50/60fps
3K (9:16): 1728×3072@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps |
| Slow Motion |
4K (16:9): 3840×2160@120fps
2.7K: 2688×1512@120fps
1080p: 1920×1080@120/240fps |
| Hyperlapse |
4K/2.7K/1080p@25/30fps: Auto/2x/5x/10x/15x/30x |
| Time Lapse |
4K/2.7K/1080p@25/30fps
Interval: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 seconds Shooting time: 5/10/20/30 minutes, 1/2/3/5 hours, infinity |
| Motionlapse |
4K/2.7K/1080p@25/30fps
Interval: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 seconds; Recording time: 5/10/20/30 minutes, 1/2/3/5 hours
Supports 4 position settings |
| Low-light video |
4K (16:9): 3840×2160@24/25/30fps
1080p: 1920×1080@24/25/30fps |
| Maximum Video Bitrate |
130 Mbps |
| Supported File Systems |
exFAT |
| Photo Format |
JPEG/RAW |
| Video Format |
MP4 (H.264/HEVC) |
| Built-in storage capacity |
This camera does not have built-in storage and records video using an inserted microSD card. |
| Audio Output |
48 kHz 16-bit, AAC |
| battery |
| kinds |
LiPo |
| capacity |
1300mAh |
| amount of electricity |
10.01 Wh |
| Voltage |
7.70 V |
| Device Temperature |
0℃ to 40℃ |
| Charging temperature range |
5℃ to 45℃ |
| Operating time |
166 minutes
Measured at 25°C (77°F) with 1080p/24fps (16:9) video recording, Wi-Fi off, and screen off. This data is for reference only.
|
| Charging time |
16 minutes to 80% charge, 32 minutes to 100% charge. Measured in a lab environment using a DJI 65W PD-compatible charger (sold separately).
|
| connection |
| Wi-Fi operating frequency |
2.400 to 2.4835 GHz
5.150 to 5.250 GHz
5.725 to 5.850 GHz (In Japan, only the 2.4 GHz band can be used) |
| Wi-Fi protocols |
802.11 a/b/g/n/ac |
| Wi-Fi Transmission Power (EIRP) |
2.4 GHz:
< 23 dBm (FCC)
<20 dBm (CE/SRRC/MIC (Japan))
5.1 GHz:
< 23 dBm (FCC/SRRC)
< 20 dBm (CE)
5.8 GHz:
< 23 dBm (FCC/SRRC)
< 14 dBm (CE) |
| Bluetooth operating frequency |
2.400 to 2.4835 GHz |
| Bluetooth Transmit Power (EIRP) |
< 14 dBm |
| Bluetooth protocol |
BLE 5.2, BR/EDR |
