| aircraft |
| Takeoff weight |
820g |
| Dimensions (including blade) |
Folded: 210 x 104 x 85 mm
Unfolded: 430 x 517 x 85 mm |
| Wheelbase |
368mm |
| Maximum Ascent Speed |
8m/s (sports), 5m/s (normal), 3m/s (stable) |
| Maximum descent speed |
4m/s (sport), 3m/s (normal), 2m/s (stable) |
| Maximum flight speed (no wind, near sea level) |
19m/s (sports), 10m/s (normal), 5m/s (stable) |
| Maximum takeoff altitude |
5000 meters |
| Maximum flight time (no wind) |
40 minutes |
| Maximum hovering time (no wind) |
38 minutes |
| Maximum flight distance (no wind) |
24km |
| Maximum wind resistance |
Level 7 |
| Maximum tilt angle |
33° (movement), 25° (normal), 25° (stable) |
| maximum angular velocity |
200° (movement), 120° (normal), 60° (stable) |
| Operating temperature |
-10°C to 40°C |
| Operating frequency |
2.400-2.4835GHz, 5.725-5.850GHz, 5.150-5.250GHz |
| Transmission power (EIRP) |
FCC: ≤30dBm |
| GNSS |
GPS |
| Hovering Accuracy |
Vertical: ±0.1m (with visual positioning active), ±0.5m (with GPS positioning). Horizontal: ±0.3m (with visual positioning active), ±1.5m (with GPS positioning). |
|
| EVO Lite+ Gimbal |
| Mechanical Range |
Pitch: -135° to 45°
Roll: -45° to 45°
Yaw: -90° to 90° |
| Controllable range |
Pitch: -90° to +30°
Yaw: -80° to +80° |
| Stability |
3-axis |
| Maximum control speed (pitch) |
30°/sec |
| Angular Vibration Range |
±0.003° |
| Sensing System |
| forward |
Accurate measurement range: 0.5~18m
Effective detection speed: <12m/s
FOV: horizontal <70°, vertical <88° |
| backward |
Accurate measurement range: 0.5~18m
Effective detection speed: <12m/s
FOV: horizontal <40°, vertical <30° |
| Downward |
Accurate measurement range: 0.5~22m
Visual hovering range: 0.5-40m
FOV: horizontal <40°, vertical <30° |
| Operating environment |
Forward, backward:
Surface with clear pattern and adequate lighting (lux > 15) Facing Down:
Surfaces with clear patterns and adequate lighting (lux > 15). Detects diffuse reflective surfaces (> 20%) (walls, trees, people, etc.) |
|
| EVO Lite+ Camera |
| sensor |
CMOS: 1 inch Effective pixels: 20M
Pixel size: 2.4μm*2.4μm |
| lens |
FOV: 82°
Equivalent focal length: 29mm
Aperture: f/2.8 to f11
Focus range: 0.5m to ∞
Focus mode: CDAF/MF |
| Shooting Mode |
Auto mode (P gear): EV is adjustable, shutter/aperture is not adjustable, ISO is auto or adjustable.
Manual mode (M gear): ISO/shutter/aperture are adjustable, EV is not adjustable.
Shutter Priority (S-file): Shutter/EV adjustable, Aperture auto, ISO auto or adjustable.
Aperture priority (A gear): Aperture/EV adjustable, shutter automatic, ISO automatic or adjustable. |
| ISO Range |
Video: ISO100 to ISO6400
Photography: ISO100 to ISO6400
Night Scene Mode: ISO up to 64000 |
| Shutter speed |
Photo mode:
1/8000 to 8 seconds Others: 1/8000 to 1/frame rate |
| Portrait Blur |
Real-time image transmission portrait blur and photo portrait blur |
| Anti-fog mode |
support |
| Zoom Range |
Digital zoom: 1-16x Lossless zoom: 4K: 1.3x; 1080p: 3x Note:
6K: Digital zoom
4K: 1.3 times faster than digital, below is lossless
1080P: More than 3 times faster than digital, below is lossless |
| Photo Format |
JPG (10-bit) / DNG (12-bit) / JPG + DNG |
| Photo resolution |
5472x3648 (3:2)
5472x3076 (16:9)
3840x2160 (16:9) |
| Photo shooting mode |
Single Shot Burst Shoeing: 3/5
Auto Exposure Bracketing (AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG minimum 5s)
HDR imaging: 5472x3648 / 3840x2160
HyperLight: 5472x3648/3840x2160 |
| Video Coding Format |
H265/H264 |
| Video resolution |
5472x3076 (P30/25/24)
3840x2160 (P60/50/48/30/25/24)
2720x1528 (P60/50/48/30/25/24)
1920x1080 (P120/60/50/48/30/25/24)
HDR:
3840x2160 (p30/25/24)
2720x1528 (p60/50/48/30/25/24)
1920x1080 (p60/50/48/30/25/24) |
| Maximum Bitrate |
120Mbps |
| Time Lapse |
Original image: 5472*
3076/3840*2160, JPG/DNG Video: 5.4K/4K P25 |
| Panorama |
Horizontal/Vertical/Wide Angle/Spherical Original image: 5472*3648, JPG/DNG |
| Supported File Systems |
Fat32, exFat |
| Video Format |
MP4/MOV |
| WIFI Transfer |
20MB/sec |
| Transmitter and image transmission |
| Operating frequency |
2.400-2.4835GHz, 5.725-5.850GHz, 5.150-5.250GHz |
| Maximum transmission distance (unobstructed and free from interference) |
FCC: 12km *Frequency bands available in Japan may differ.
|
| Operating temperature |
0°C to 40°C |
| Transmission power (EIRP) |
FCC: ≤30dBm |
| Battery capacity |
3930mAh |
| Maximum Battery Life |
~3.5h (when connected to a mobile phone)
~2.5h (when not connected to a mobile phone) |
| Interface Type |
Type C |
| Transmission System |
Autel SkyLink |
| Real-time transmission quality |
Transmission distance < 1km: 2.7K30fps
Transmission distance > 1km: 1080P 30fps |
| Transmission Bit Rate |
90Mbps |
| Transmission Delay |
≤200ms |
| adapter |
| input |
100-240V / 50-60HZ |
| output |
12.75V⎓5A |
| Rated Output |
63.75W |
| Aircraft batteries |
| capacity |
6175mAh |
| Voltage |
11.13V |
| Maximum Charging Voltage |
12.75V |
| Battery Type |
Li-Po 3S |
| Energy |
68.7Wh |
| charging temperature |
5 to 45°C |
| Single Battery Charging Time |
90 minutes |
| Maximum charging power |
78W |
| App |
| Mobile App |
Autel Sky |
| Compatible smartphone versions |
iOS 12.0 or later, Android 8.0 or later |
| Storage |
| Internal storage |
6GB |
| SD storage |
Supports up to 256GB (UHS-3 rating required) |
Equipped with a 1-inch CMOS image sensor and Autel's intelligent moonlight algorithm, the EVO Lite+ captures clear, low-noise photos even at high ISO settings at night. The adjustable aperture ranges from F2.8 to F11, allowing you to change exposure and depth of field.
The superior transmission system "Autel SkyLink" achieves a transmission distance of up to approximately 12km*, real-time 2.7K/30FPS video transmission, and excellent interference prevention. *Frequency bands available in Japan may differ.
Autel's latest ultra-wide-angle obstacle avoidance sensors are installed in the front, rear, and bottom of the aircraft, providing a 150-degree frontal field of view, eliminating more blind spots than traditional systems while reducing the number of cameras required.
The EVO Lite offers up to 40 minutes of battery life, the longest of any drone of its size in the industry, and 30% more flight time than competitors.
